Cast Iron Ball Mill Liners
Mill liner is a protective material used inside ball mills, usually made of highly wear-resistant materials in the form of plate components, used to cover the inner walls of ball mills to extend their lifespan. The function of the ball mill liner is to protect the cylindrical shell and the material inside it from being impacted and worn by the grinding media (such as steel balls) and the raw material being ground.The mill liner also helps to enhance the grinding performance of the ball mill by increasing the surface area of the grinding media and improving the lifting effect of the balls, which helps to promote the grinding process.
Product Description
What is Cast Iron Ball Mill Liners?
The Cast iron ball mill liners are an essential component in various industrial processes, particularly in grinding operations. These liners are meticulously crafted to withstand the rigorous conditions within ball mills, ensuring optimal performance and extended service life. At Ninghu, we pride ourselves on delivering high-quality iron mill liners that meet the stringent demands of our customers.
Performance Characteristics:
- Exceptional Wear Resistance: The cast iron ball mill liners are engineered to withstand abrasion and impact, prolonging the lifespan of the mill and reducing maintenance costs.
- Optimized Design: The liners are precisely designed to maximize grinding efficiency by promoting proper trajectory and distribution of grinding media within the mill.
- Corrosion Resistance: With a protective layer against corrosion, our liners maintain their integrity even in harsh chemical environments.
- Heat Resistance: The robust construction of our liners ensures stability under high temperatures, preventing deformation and maintaining dimensional accuracy.
- Easy Installation and Maintenance: Designed for hassle-free installation and maintenance, our iron mill liners facilitate quick replacement, minimizing downtime and optimizing productivity.
Specifications:
| Chemical Composition | |||||||||||||||
| Series No. |
Type | Designation | Chemical Composition | Mechanical Properties | Microstructure | ||||||||||
| C | Si | Mn | Cr | Mo | Ni | Cu | S | P | ak(J/cm²） | HRC | σb(Mpa) | ||||
| 1 | Medium carbon and medium chromium I | ZG30Cr5MoRE | 0.25~0.40 | 0.3~1.0 | 0.3~1.0 | 4.5~5.5 | 0.2~1.0 | ≤0.045 | ≤0.045 | ≥25 | ≥45 | M+B+C | |||
| 2 | Medium carbon and medium chromium II | ZG40Cr5MoRE | 0.30~0.45 | 0.3~1.0 | 0.3~1.0 | 4.5~5.5 | 0.2~1.0 | ≤0.045 | ≤0.045 | ≥20 | ≥48 | M+B+C | |||
| 3 | Medium carbon and low alloy | ZG40CrMoNiRE | 0.30~0.50 | 0.3~1.5 | 0.3~1.0 | 1.2~1.8 | 0.2~0.6 | 0.1~0.4 | ≤0.04 | ≤0.04 | ≥30 | ≥40 | M+F | ||
| 4 | Low carbon high alloy | ZG20Cr9NiMo | 0.15~3.50 | ≤1.0 | 0.3~1.0 | 8~10 | 0.4~0.8 | 1.4~1.8 | ≤0.1 | ≤0.045 | ≤0.045 | ≥40 | ≥40 | M+C | |
| 5 | Alloy steel with chromium+molybdenum+nickel | ZG45Cr3NiMoMnRE | 0.30~0.50 | 0.3~0.8 | 0.3~1.2 | 2.0~3.2 | 0.3~0.5 | 0.5~1.0 | ≤0.04 | ≤0.04 | ≥20 | ≥50 | M+C | ||
| 6 | Alloy steel with 90 chromium | ZG90Cr6MoMn | 0.85~0.95 | 0.4~0.8 | 0.4~0.8 | 5~8 | 0.2~0.4 | ≤0.045 | ≤0.045 | ≥7 | ≥50 | M+C | |||
| 7 | Ordinary high manganese steel | ZGMn13 | 1.1~1.4 | 0.3~1.0 | 11~14 | ≤0.06 | ≤0.10 | ≥147 | Hb≤229 | 637 | A | ||||
| 8 | Modified high manganese steel | ZGMn13cr2 | 1.0~1.5 | 0.3~1.0 | 11~14 | 0.5~4.0 | ≤0.06 | ≤0.10 | ≥80 | ≤240 | A+C | ||||
| 9 | Ultra-high manganese steel | ZGMn17cr2 | 1.0~1.5 | 0.3~1.0 | 16~19 | 1.0~4.0 | Ti0.2~0.4 | ≤0.06 | ≤0.10 | ≥50 | ≤260 | A+C | |||
| 10 | High chromium cast iron | KmTBCr15Mo2 | 2.0~2.8 | ≤1.2 | 0.5~1.0 | 13~18 | 0.2~2.5 | 0~1.0 | 0~1.2 | ≤0.06 | ≤0.10 | ≥53 | M+A+C | ||
| 11 | High chromium cast iron | KmTBCr20Mo2 | 2.0~3.0 | ≤1.2 | 0.5~1.0 | 18~22 | 1.5~2.5 | 0~1.5 | 0.8~1.2 | ≤0.06 | ≤0.10 | ≥3 | ≥58 | M+A+C | |
| 12 | High chromium cast iron | KmTBCr26 | 2.0~3.0 | ≤1.2 | 0.5~1.0 | 23~28 | 0~1.0 | 0~1.5 | 0~2.0 | ≤0.06 | ≤0.10 | ≥55 | M+A+C | ||
| 13 | High chromium cast steel | ZGCr12SiMn-GT | 1.0~2.0 | ≤1.2 | 0.5~2.0 | 12~14 | 0~1.0 | 0~1.0 | 0~1.0 | ≤0.06 | ≤0.10 | ≥3.2 | ≥55 | M+A+C | |
| 14 | High chromium cast steel | ZGCr15SiMn-GT | 1.0~2.0 | ≤1.2 | 0.5~2.0 | 15~17 | 0~1.0 | 0~1.0 | 0~1.0 | ≤0.06 | ≤0.10 | ≥3.5 | ≥55 | M+A+C | |
| M-Martensite B-Bainite A-Austenite C-Carbide F-Ferrite | |||||||||||||||
Application Fields:
- Mining Industry: Utilized in ore processing plants for grinding various minerals, our liners ensure consistent particle size reduction and optimal mineral recovery.
- Cement Manufacturing: Employed in cement mills, our liners contribute to the efficient grinding of clinker, enhancing the quality of the final cast iron ball mill liner.
- Power Generation: Used in coal mills, our liners aid in pulverizing coal to fine particles, facilitating efficient combustion and energy generation.
- Chemical Processing: Suitable for chemical mills, our martensitic white iron liners for rod mills endure corrosive substances and provide reliable performance in chemical processing applications.
Market Trends:
- Increasing Demand for Efficiency: With industries emphasizing productivity and cost-effectiveness, there's a growing demand for high-performance mill liners that optimize grinding processes.
- Focus on Sustainability: As sustainability becomes a key priority, there's a shift towards durable and long-lasting liners that reduce material consumption and environmental impact.
- Technological Advancements: Innovations in material science and manufacturing processes are leading to the development of advanced liners with superior performance and longevity.
- Global Expansion: With expanding industrial activities worldwide, particularly in emerging economies, there's a rising need for reliable mill liners to support infrastructure development.
Quality Assurance:
At Ninghu, quality reigns supreme. As a premier manufacturer of wear-resistant materials, we leverage advanced production technology and top-tier facilities. Our fully automated production line guarantees uniformity and accuracy across all the cast iron ball mill liners. Boasting an annual production capacity of 50,000 tons, we fulfill customer needs with utmost efficiency and excellence. Moreover, our adherence to the ISO9001 quality system certification underscores our dedication to superior quality and reliability. Trusted by key domestic importers and exporters, Ninghu continues to set the standard for excellence in the industry, ensuring customer satisfaction and trust in every endeavor.
Why Choose Us?
- Advanced Manufacturing Facilities: Our fully automated production line ensures precision engineering and consistent quality control, guaranteeing superior martensitic white iron liners for rod mills.
- Customization Options: We offer tiron mill liners to meet specific requirements, providing flexibility and versatility to our customers.
- Abundant Inventory: With sufficient inventory, we ensure prompt delivery, minimizing lead times and optimizing operational efficiency.
- Exceptional Customer Support: Our dedicated team provides comprehensive assistance, from product selection to after-sales service, ensuring a seamless experience for our clients.
